CattleMaster 480

SKU: #18248

CattleMaster fountains provide the best of both worlds: blending technology from traditional stainless steel units and the newest poly units, to provide a premier livestock waterer. Featuring thermostatically controlled heat for ice-free operation and Ritchie’s fast refill valve, Cattlemaster fountains will satisfy your herd’s hydration needs in any climate. The casing of the CattleMaster 480 is made from Ritchie’s heavy-duty, impact resistant polyethylene construction. The roto-molded construction is heavily insulated for energy efficiency and employs UV inhibitors for extended life.

Herd Capacity

Beef: 200
Dairy: 100

Not sold online, locate a dealer or call 1-800-747-0222.

Features

Install using the same concrete pad and drain-out configuration as the CattleMaster 48
Unique water seal technology keeps cold air away from valve
Electric heat standard; attached directly under the trough for maximum performance
Cable heater provides extra valve and supply line protection
Trough and hardware is 304 stainless steel for durability and long life
Fully adjustable thermostat
Meets Grade A dairy recommendations
Constant flow optional
Trough slopes toward drain for quick and easy cleaning
10 year warranty

CattleMaster 480 Instruction Manual

Specifications & Support

*Package dimensions are listed for individual parts for shipping purposes

Part No.: 18248
Length: 51in/129.54cm
Width: 23.5in/59.69cm
Overall Height: 24in/60.96cm
Shipping Weight: 90lb/40.82kg
Drinking Height: 16in/40.64cm
Heat: 548W
Capacity: 20gal/75.71L
Herd Capacity: 200 beef, 100 dairy

CattleMaster 480 Parts Breakdown CattleMaster 480 Footprint

CattleMaster 480 Videos

Ritchie Industries, adjusting the fenwal thermostat on larger automatic waterers

Ritchie automatic waterers come in a variety of sizes. The larger, heat standard units are available with an adjustable fenwal thermostat. This video highligh…

How to change the 3/4" valve rubber on larger Ritchie waterers

The valve rubber in the Omni 3, Omni 5 and CattleMaster series may need to be changed due to normal wear and tear or due to a buildup of deposits carried throug…
